220V 32 Heads 4 Products 1020g Combination Weigher

Mixing 4 Products 32 Head Weigher For Weighing And Mixing With 1.6L Hopper

32 combined weighing machine can mix up to 4 kinds of materials, suitable for batching and processing of granular products with good fluidity, such as nuts, beans and seeds. The 32-head mixed multi-head weighing machine is a composite weighing machine composed of 32 hoppers. Separate upper hopper is used for mixing all kinds of mixed formula materials. We use the "stable time development model" in our programming and development.

Features

1. The weight of the mixture can be automatically compensated by the last material.

2. Adopt high precision and high standard special sensors.

3. Intelligent fault alarm prompts make maintenance more convenient.

4. High-speed asynchronous discharge function, effectively prevent material blocking.

5. Modbus industry-standard communication protocol, realizing the integration of the interface between the combined balance and the packaging machine.

6. Can use for 2 in 1, 3 in 1 and 4 in 1 mixing products.

7. 32 head hopper combinations, higher weighing accuracy.

8. New highly integrated modular design, using CAN bus technology.

Mechanical character

1. Separable upper hoppers are used for a variety of mixed formula materials.
2. Independent main vibration machine is used to control the feed thickness of different materials.
3. Unified design standards and die production process, so that each part more interchangeability.
4. Stable aluminum housing structure, so that the hopper operation more stable, more accurate reading, the overall chassis and middle seat to enhance the strength of the machine, so that the hopper stabilization time is shorter.
5. The other 24-head hybrid miniature and 32-head 4-head hybrid types are optional.
6. The whole box and middle seat enhance the rigidity and strength of the machine and make the weighing more accurate.

Technical specification

Application

Suitable for quantitative weighing of granular materials, tea leaves, Chinese herbal medicine, seeds, beans, coffee beans, chocolate beans, nuts, monosodium glutamate, chicken essence, and other small quantities.

Molds and components: Key components such as hoppers, vibrating pans, waterproof cover are made by high-precision molds, which have high consistency and interchangeability; Sensors we use is from Japan and Germany well-known brand; Circuit board is in excellent industrial-standard design, which the chip selection, PCB design, and protection are based on the industrial-grade materials and the production process.

Accuracy: Taking into consideration that the mode of the main vibrator and linear vibrator and vibration absorption ability of the framework that has the effect to weigher accuracy, Kenwei independent research and develop both standard and high amplitude vibrators to meet the needs of different materials. Also control the vibrating time and amplitude separately by control systems to automatically adjust the linear vibrator amplitude, which makes the material flow optimization; About the middle base of machine case, we always use 2.5mm-3.0mm stainless steel sheet and strengthen the internal structure by providing reinforcement to ensure the machine's rigidity. Some models take the machine case and middle base integrated, through a combination of AD converter module and anti-jamming technology, which effectively reduce the vibrating interference and ensure the accuracy of the machine running.

Product customization

A. We have a technical team with a rapid response for special projects to meet the different requirements for customers.

B.10 years of experience in product customization, rich practical application of industry experience

C. According to the actual situation of enterprises, research production characteristics to make a comprehensive assessment of planning programs with high adaptability.
